Omron CP1H CPU

657
Auxiliary Area Allocations by Address Appendix D
A342 A342.03 Memory Cas-
sette Write
Flag
ON when data is being written to the
Memory Cassette.
OFF: Not writ-
ing
ON: Writing
Retained Cleared --- ---
A342.04 Memory Cas-
sette Read
Flag
ON when data is being read from the
Memory Cassette.
OFF: Not
reading
ON: Reading
Retained Cleared --- ---
A342.05 Memory Cas-
sette Verify
Flag
ON when data is being compared
with data on the Memory Cassette.
OFF: Not veri-
fying
ON: Verifying
Retained Cleared --- ---
A342.07 Memory Cas-
sette Initializa-
tion Error Flag
ON when an error occurs in initializ-
ing the Memory Cassette.
OFF the next time the Memory Cas-
sette is accessed normally (initial-
ized, written, read, or compared).
OFF: No error
ON: Error
Retained Cleared --- ---
A342.08 Memory Cas-
sette Write
Error Flag
ON when an error occurs in writing
the Memory Cassette.
OFF the next time the Memory Cas-
sette is accessed normally (initial-
ized, written, read, or compared).
OFF: No error
ON: Error
Retained Cleared --- ---
A342.10 Memory Cas-
sette Read
Error Flag
ON when an error occurs in reading
the Memory Cassette.
OFF the next time the Memory Cas-
sette is accessed normally (initial-
ized, written, read, or compared).
OFF: No error
ON: Error
Retained Cleared --- ---
A342.12 Memory Cas-
sette Mis-
match Flag
ON the data in the CPU Unit is not
the same as the data in the Memory
Cassette when a verification opera-
tion is performed.
OFF the next time the Memory Cas-
sette is accessed normally (initial-
ized, written, read, or compared).
OFF: Match
ON: Mis-
match
Retained Cleared --- ---
A342.13 Memory Cas-
sette Access
Flag
ON when the Memory Cassette is
being accessed.
OFF when access is completed.
OFF: Not
being
accessed
ON: Being
accessed
Cleared --- ---
A342.15 Memory Cas-
sette Flag
ON when a Memory Cassette is
mounted.
OFF when a Memory Cassette is not
mounted.
OFF: No
Memory Cas-
sette
ON: Memory
Cassette
mounted
Retained Cleared --- ---
A345 A345.00 FB Program
Data Flag
Turns ON if the FB program memory
contains FB program data.
OFF: No data
ON: Data
present
Retained Cleared Download-
ing pro-
grams from
CX-Pro-
grammer
or Memory
Cassette
or clearing
VM
---
A345.01 Program Index
File Flag
Turns ON when the comment mem-
ory contains a program index file.
OFF: No file
ON: File
present
Download-
ing pro-
grams from
CX-Pro-
grammer
or Memory
Cassette
A345.02 Comment File
Flag
Turns ON when the comment mem-
ory contains a comment file.
OFF: No file
ON: File
present
A345.03 Symbol Table
File Flag
Turns ON when the comment mem-
ory contains a symbol table file.
OFF: No file
ON: File
present
A345.04 DM Initial Val-
ues Flag
ON when DM initial values are stored
in the flash memory.
OFF: No val-
ues stored
ON: Values
stored
--- --- --- ---
Address Name Function Settings Status
after
mode
change
Status
at star-
tup
Write
timing
Related
flags, set-
tings
Words Bits
