673
Auxiliary Area Allocations by Address Appendix D
A540 A540.10 Pulse Out-
put 0 Posi-
tioning
Completed
Signal
This is the positioning completed
input signal used in the origin search
for pulse output 0. The input signal
from the servo driver is output to this
bit from the ladder program to enable
using the signal.
--- --- Cleared ---
A541 A541.00 Pulse Out-
put 1 Reset
Bit
The pulse output 1 PV (contained in
A278 and A279) will be cleared when
this bit is turned ON.
--- --- Cleared --- A278 and
A279
A541.08 Pulse Out-
put 1 CW
Limit Input
Signal Flag
This is the CW limit input signal for
pulse output 1, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- Cleared --- ---
A541.09 Pulse Out-
put 1 CCW
Limit Input
Signal Flag
This is the CCW limit input signal for
pulse output 1, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- Cleared --- ---
A541.10 Pulse Out-
put 1 Posi-
tioning
Completed
Signal
This is the positioning completed
input signal used in the origin search
for pulse output 1. The input signal
from the servo driver is output to this
bit from the ladder program to enable
using the signal.
--- --- Cleared --- ---
A542 A542.00 Pulse Out-
put 2 Reset
Bit
The pulse output 2 PV (contained in
A322 and A323) will be cleared when
this bit is turned ON.
--- --- Cleared --- A322 and
A323
A542.08 Pulse Out-
put 2 CW
Limit Input
Signal Flag
This is the CW limit input signal for
pulse output 2, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- Cleared --- ---
A542.09 Pulse Out-
put 2 CCW
Limit Input
Signal Flag
This is the CCW limit input signal for
pulse output 2, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- Cleared --- ---
A542.10 Pulse Out-
put 2 Posi-
tioning
Completed
Signal
This is the positioning completed
input signal used in the origin search
for pulse output 2. The input signal
from the servo driver is output to this
bit from the ladder program to enable
using the signal.
--- --- Cleared ---
A543 A543.00 Pulse Out-
put 3 Reset
Bit
The pulse output 3 PV (contained in
A324 and A325) will be cleared when
this bit is turned ON.
--- --- --- --- A324 and
A325
A543.08 Pulse Out-
put 3 CW
Limit Input
Signal Flag
This is the CW limit input signal for
pulse output 3, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- --- --- ---
A543.09 Pulse Out-
put 3 CCW
Limit Input
Signal Flag
This is the CCW limit input signal for
pulse output 3, which is used in the
origin search. To use this signal,
write the input from the actual sensor
as an input condition in the ladder
program and output the result to this
flag.
--- --- --- --- ---
Addresses Name Function Settings Status
after
mode
change
Status at
startup
Write
timing
Related
Flags,
Settings
Word Bits
