49
Specifications Section 2-2
Note The above values are for a cold start at room temperature for an AC power
supply, and for a cold start for a DC power supply.
• A thermistor (with low-temperature current suppression characteristics) is
used in the inrush current control circuitry for the AC power supply. The
thermistor will not be sufficiently cooled if the ambient temperature is high
or if a hot start is performed when the power supply has been OFF for
only a short time, so in those cases the inrush current values may be
higher (as much as two times higher) than those shown above.
• A capacitor delay circuit is used in the inrush current control circuitry for
the DC power supply. The capacitor will not be charged if a hot start is
performed when the power supply has been OFF for only a short time, so
in those cases the inrush current values may be higher (as much as two
times higher) than those shown above.
• Always allow for this when selecting fuses and breakers for external cir-
cuits.
Characteristics
Insulation resistance 20 MΩ min. (at 500 VDC) between the external
AC terminals and GR terminals
No insulation between primary and secondary
DC power supplies.
Dielectric strength 2,300 VAC 50/60 Hz for 1 min between the
external AC and GR terminals, leakage current:
5 mA max.
No insulation between primary and secondary
DC power supplies.
Noise resistance Conforms to IEC 61000-4-4 2 kV (power supply line)
Vibration resistance
10 to 57 Hz, 0.075-mm amplitude, 57 to 150 Hz, acceleration: 9.8 m/s
2
in X, Y, and Z directions for
80 minutes each (time coefficient of 8 minutes × coefficient factor of 10 = total time of 80 minutes)
Shock resistance
147 m/s
2
three times each in X, Y, and Z directions
Ambient operating
temperature
0 to 55°C
Ambient humidity 10% to 90% (with no condensation)
Atmosphere No corrosive gas.
Ambient storage
temperature
−20 to 75°C (excluding battery)
Terminal screw size M3
Power interrupt time 10 ms min. 2 ms min.
Weight 740 g max. 590 g max. 560 g max.
Power supply
classification
AC power supply DC power supply
Model numbers • XA CPU Units
CP1H-XA40DR-A
• X CPU Units
CP1H-X40DR-A
• XA CPU Units
CP1H-XA40DT-D
CP1H-XA40DT1-D
• X CPU Units
CP1H-X40DT-D
CP1H-X40DT1-D
• Y CPU Units
CP1H-Y20DT-D
Type X CPU Units XA CPU Units Y CPU Units
Model CP1H-X40DR-A
CP1H-X40DT-D
CP1H-X40DT1-D
CP1H-XA40DR-A
CP1H-XA40DT-D
CP1H-XA40DT1-D
CP1H-Y20DT-D
Program capacity 20 Ksteps
Control method Stored program method
I/O control method Cyclic scan with immediate refreshing
Program language Ladder diagram
