Specifications Section 2-2
Analog I/O Specifications
Note (1) The built-in analog input switch is used for toggling between voltage input
and current input. (The default setting at the time of shipping is for voltage
input.)
(2) Switching between 1/6,000 and 1/12,000 resolution is done in the PLC
Setup. The same resolution setting is used for all I/O words. It is not pos-
sible to set them individually.
(3) The total conversion time is the total of the conversion times for all the
points that are used. It would be 6 ms for 4 analog inputs and 2 analog
outputs.
(4) When the analog current output is within 0 to 20 mA, the accuracy cannot
be ensured if below 0.2 mA.
Model CP1H-XA40DR-A
CP1H-XA40DT-D
CP1H-XA40DT1-D
Item Voltage I/O (See note 1.) Current I/O (See note 1.)
Analog
Input Sec-
tion
Number of
inputs
4 inputs (4 words allocated)
Input signal
range
0 to 5 V, 1 to 5 V, 0 to 10 V, or −10 to 10 V 0 to 20 mA or 4 to 20 mA
Max. rated input ±15 V ±30 mA
External input
impedance
1 MΩ min. Approx. 250 Ω
Resolution 1/6000 or 1/12000 (full scale) (See note 2.)
Overall accu-
racy
25°C: ±0.3% full scale/0 to 55°C: ±0.6% full
scale
25°C: ±0.4% full scale/0 to 55°C: ±0.8% full
scale
A/D conversion
data
Full scale for −10 to 10 V: F448 (E890) to 0BB8 (1770) hex
Full scale for other ranges: 0000 to 1770 (2EE0) hex
Averaging func-
tion
Supported (Set for individual inputs in the PLC Setup.)
Open-circuit
detection func-
tion
Supported (Value when disconnected: 8000 hex)
Analog Out-
put Section
Number of out-
puts
2 outputs (2 words allocated)
Output signal
range
0 to 5 V, 1 to 5 V, 0 to 10 V, or −10 to 10 V 0 to 20 mA or 4 to 20 mA (See note 4.)
Allowable exter-
nal output load
resistance
1 kΩ min. 600 Ω max.
External output
impedance
0.5 Ω max. ---
Resolution 1/6000 or 1/12000 (full scale) (See note 2.)
Overall accu-
racy
25°C: ±0.4% full scale/0 to 55°C: ±0.8% full scale
D/A conversion
data
Full scale for −10 to 10 V: F448 (E890) to 0BB8 (1770) hex
Full scale for other ranges: 0000 to 1770 (2EE0) hex
Conversion time 1 ms/point (See note 3.)
Isolation method Photocoupler isolation between analog I/O terminals and internal circuits. No isolation
between analog I/O signals.
