2-5 Creating Virtual Network Configurations Offline
2-5-3 Changing Node Addresses
2-5-3 Changing Node Addresses
Component − Change Node Address
Node address between 0 and 63 will be automatically assigned to devices as they are
added to the network.
Use the following procedure to change a node address that has been assigned.
1 Select the device for which the node address is to be changed.
2 Select Component
−
Change Node Address from the menu bar. Alternately,
right-click the device and select Change Node Address from the pop-up menu.
The Change Node Address Dialog Box will be displayed.
3 Change the node address to a value between 0 and 63 and click the OK Button.
The node address will be changed.
Repeat this operation to change any other node address in the network that should
be different.
2-34
