4-3 Manually Setting Data Links
4-3-12 Starting and Stopping Data Links (Including Status Displays)
4-3-12 Starting and Stopping Data Links (Including Status Displays)
Before performing the operations described below, connect online to a node where the
data link table has been transferred. As long as the data link table is stored there, data
link starting and stopping can be executed from any node.
Note
When starting data links with manual setup, the data link mode for the startup node
must be set to manual.
Starting Data Links
1 Select Tools - Start Data Link from the menu bar.
The Select Network Dialog Box will be displayed. (For local network only, i.e., when
network address is 0.)
2 Select Controller Link or SYSMAC LINK, and then click the OK Button.
Either the Datalink Component (Controller Link) or Datalink Component (SYSMAC
LINK) Window will be displayed.
4-39
