4-4 Automatically Set Data Links
4-4-2 Controller Link Automatic Setup
4-4-2 Controller Link Automatic Setup
1 Before executing the following operations, connect online to the PLC that is serving
as the startup node (making it the target PLC).
Select Network - Work Online or Network - Auto Online from the menu bar.
2 Right-click the Controller Link Unit or SYSMAC LINK Unit in the Online Connection
Information Window and select Start Data Link from the popup menu. Either the
Datalink Component (Controller Link) or Datalink Component (SYSMAC LINK)
Window will be displayed.
Note: Start Data Link cannot be selected if there is not a Controller Link Unit or SYSMAC
LINK Unit mounted in the PLC that is connected online.
3 Select Automatic Datalink Setup from the Online Menu.
The Automatic Datalink Dialog Box will be displayed.
4-42
To Next Page
