6-6 Parameter Wizard
6. Slave Registration/Deletion
The following Scan List Wizard - Set Memory Block’s Start Word Dialog Box will be
displayed.
Specify the slave to be registered with the master and click the Next Button.
The devices on the network are shown in the Registered Device List.
To cancel the registration of a device, click the following icon:
The user cannot go to the next step if no devices are registered.
7. The following Scan List Wizard-Allocated Result Dialog Box will be displayed after
remote I/O allocations have been made as specified.
Click the Finish Button if the displayed details are OK. The Parameter Wizard will
finish. The user can click the Back Button to return to the previous dialog box.
The displayed details will be set as device parameters.
6-19
To Next Page
