6-9 Advanced Settings (Connection, Communication Cycle Time, Slave Function
Settings, Etc.)
6-9-5 Setting/Canceling Explicit Message Communications
6-9-5 Setting/Canceling Explicit Message Communications
Component - Parameter - Edit - General Tab - Explicit Message
Communications Box
Note: This procedure is supported for the CVM1-DRM21-V1 and C200HW-DRM21-V1 only.
Specify whether or not to enable explicit message communications (transmissions
only) without remote I/O communications. Check the box to enable explicit message
communications only.
Note
For the CS1W-DRM21(-V1) and CJ1W-DRM21, slaves with explicit message
communications only do not have to be registered. Explicit message communications is
possible regardless of the scan list registration.
6-9-6 Starting Remote I/O Communications
Component - Parameter - Edit - General Tab - Start Remote I/O
Communication at Start-Up Box
Note: This procedure is supported for the CVM1-DRM21-V1 and C200HW-DRM21-V1 only.
Specify whether or not to enable remote I/O communications automatically. Check the
box to start remote I/O communications automatically when the master is started.
Note
For the CS1W-DRM21(-V1) and CJ1W-DRM21, remote I/O communications upon
start-up can be disabled by disabling the master function.
Select Component then click the Unit Function Tab of the Property Window, and
remove the check mark from Enable Master Function.
6-42
