1-1 The CX-Integrator
1-1-4 Accessible Network
Local Network Table Requirements
A local network table must be registered in the target PLC in the following cases.
Communications Conditions
Network
communications
• More than one Network Communications Unit is mounted to the target
PLC. (See note.)
Note: Network Communications Units include Ethernet Units, Controller
Link Units, SYSMAC LINK Units, DeviceNet Units, and FL-net Units.
Serial Communications Units and Serial Communications Boards are not
included except in the following case: If serial ports are registered in the
local network table to treat them as networks, the serial ports must be
treated as Network Communications Units, including the serial ports on
the CPU Unit.
• Routing tables are already registered in one or more nodes on the network.
• Communications are required between networks.
Serial
communications
Serial ports on Serial Communications Units and Serial Communications
Boards are used as serial gateways to Host Link FINS and access is
required via networks via Host Link FINS to PLCs functioning as Host Link
slaves.
Note: Serial ports do not necessarily need to be registered in the local
network table (to treat them as networks) to enable using other serial
gateway functions. Registration is normally not required to convert from
serial to serial. Refer to 3-6 Overview of Serial Gateway Functions in the
CS/CJ-series Communications Commands Reference Manual (Cat. No.
W342) for details on whether local network tables are required to use
serial gateway functions.
Note: As an exception, local network tables are not required even when more than one Network
Communications Unit is mounted in the following situation:
Access is possible without a local network table when connecting online to the target PLC via a
direct serial connection and access is required only to the network of the Network
Communications Unit with the smallest unit number (set on the front panel rotary switches) of all
the Network Communications Units that are mounted to the target PLC.
1-6
