6-14 Monitoring Devices
6-14-2 Monitoring Devices
6-14-2 Monitoring Devices
Component - Monitor
To monitor the device, use the following procedure.
1. Place the CX-Integrator online.
2. Select the device.
3. Select Component - Monitor.
A monitor dialog box for the device will be displayed.
Note
•A Slave can be monitored only if the slave has parameters that can be monitored in
the EDS file.
•Monitor cannot be selected if the device selected has no monitoring function.
4. To quit the monitor function, click the Close Button.
CS1W-DRM21(-V1) or CJ1W-DRM21 DeviceNet Unit
The monitor window for the CS1W-DRM21(-V1) or CJ1W-DRM21 makes it possible to
monitor the following items.
Tab Monitor item
Status Status of the master and slaves
Unit Status Status of the functions of the Unit
Communication Cycle Time Communication cycle time
Error History Error history
6-63
