6-14 Monitoring Devices
6-14-2 Monitoring Devices
Communication Cycle Time Tab Page
The Communication Cycle Time Tab Page displays the present, maximum, and
minimum values of communication cycle time.
The maximum or minimum value can be cleared by clicking the Clear Button.
Error History Tab Page
The Error History Tab Page displays the error history recorded in the master.
The following error history items will be displayed.
Item Description
Time of Error The time the error occurred.
Error Information Error code
Detailed Information Detailed error information
Content Contents of error
To refresh the display, click the Update Button.
To clear the error history from the master, click the Clear Button.
To save the file in CSV file format, click the Save Button.
6-68
