1-6 Menus
1-6-1 Menus
Main
menu
Sub-menu/command Description
Network
type
Offline Online
View 200% Displays components in the
Network Configuration Window at
200% of the default size.
100% Displays components in the
Network Configuration Window at
the default size.
75% Displays components in the
Network Configuration Window at
75% of the default size.
Zoom
50% Displays components in the
Network Configuration Window at
50% of the default size.
All networks OK OK
Properties Displays the properties of the
selected project, network,
component, or EDS file.
OK OK
Network Adds a new virtual network to the
Network Configuration Window
offline.
OK No
Component Adds the component selected in
the Component List Window to the
Network Configuration Window
offline.
OK No
Insert
Insert TBranch Adds a new T-branch to the
Network Configuration Window
offline (Controller Link only).
OK No
Network Work Online Switches between working offline
and online with the relay PLC
using the device type setting in
the computer.
OK OK
Communication Settings Used to change the device type
settings of the relay PLC on the
computer. The Change Dialog Box
PLC is displayed.
OK No
IP address table setting Sets the CX-Integrator IP address
table. (Only when the relay PLC is
set for Ethernet communications
and the network address is 1 or
greater.)
Ethernet only. OK OK
Auto Online Automatically connects to the
relay PLC using the
communications settings of the
PLC (supported for serial
communications only).
After the auto-connection has
been made, the device type
information of the relay PLC that
was connected to will be
uploaded.
OK No
Change connection to the PLC Switches the connection to the
selected network to enable
accessing it.
No OK
Transfer [PC to Network] Downloads all component
parameters from the virtual
network on the computer to the
components in the actual network.
No OK
Transfer [Network to PC] Uploads the network configuration
of the Communications Unit
selected in the Online Connection
Information Window, provided that
the network can be displayed and
accessed in the Workspace
Window.
No OK
Compare Compares the virtual network on
the computer to the network
configuration of the actual
networks (without component
parameters). The target PLC must
be online and accessible.
No OK
