1-6 Menus
1-6-1 Menus
Main
menu
Sub-menu/command Description
Network
type
Offline Online
Network Edit Enables editing the parameters of
the selected Controller Link
network.
All networks OK OK
Write Writes the parameters of the
selected component to a
component parameter file.
OK OK
Read Reads the parameters from a
component parameter file to a
selected component.
OK No
Transfer [PC to
Network]
Downloads all component
parameters or network parameters
from the virtual network on the
computer to the actual network.
No OK
Transfer
[Network to PC]
Uploads the network configuration
and all component parameters or
network parameters from the
actual network to the virtual
network on the computer.
No OK
Parameter
Compare Compares the network
configuration and all component
parameters or network parameters
between the actual network and
the virtual network on the
computer.
No OK
Move to upper network Displays the next higher network
layer.
DeviceNet
only
No OK
Move to lower network Displays the next lower network
layer.
DeviceNet
only
No OK
Rename Network Changes the network name. OK No
Change Network Address Changes the network address.
All networks
OK No
Update Maintenance Information Updates the device’s maintenance
information.
DeviceNet
only
No OK
Compo-
nent
Wizard Enables setting component
parameters with a wizard (for
supported components only).
DeviceNet
only
OK OK
Edit Enables editing the parameters of
the selected component.
OK OK
Load Reads the parameters from a
component parameter file to a
selected component.
All networks
OK OK
Save Saves the parameters of the
selected component to a
component parameter file.
OK OK
Download Downloads the selected
component parameters to the
actual component.
No OK
Upload Uploads the selected component
parameters from the actual
component.
No OK
Parameter
Compare Compares the selected
component parameters with those
in the actual component.
No OK
Monitor Enables monitoring the selected
component (for supported
components only).
DeviceNet
only
No OK
Reset Resets the selected component. DeviceNet
only
No OK
Start Special
Application
Start with
Settings Inherited
Starts the associated Support
Software for the selected
component or PLC, keeping the
CX-Integrator settings.
All networks OK OK
Start Only Starts the associated Support
Software for the selected
component or PLC, without
keeping the CX-Integrator
settings.
OK OK
1-36
