1-6 Menus
1-6-1 Menus
Main
menu
Sub-menu/command Description
Network
type
Offline Online
Compo-
nent
IO table Starts the I/O Table Component
online.
No OK
Error Log Display the CPU Unit error log
online.
All networks
No OK
Mode Setting Reads or changes the CPU Unit’s
operating mode online.
No OK
Maintenance information Displays the maintenance
information of the selected
component.
DeviceNet
only
No OK
Status/Error of Communication Unit Displays the status and error
information on a Communications
Unit online.
All networks No OK
Error Log of Communication Unit Displays the error log of a
Communications Unit online.
No OK
Resister to
another device
No applicable
devices
Registers the current device to the
scan list in another device.
DeviceNet
only
OK No
Change Node address Changes the node address of a
component.
All networks OK No
I/O Comment Enables editing the comments of a
DeviceNet device (component).
DeviceNet
only
OK No
Edit Device Comment Enables changing the comment of
a component.
DeviceNet
only
OK No
Start Data Link Starts the Data Link Component. OK OK
Start Routing Table Starts the Routing Table
Component.
All networks
OK OK
NT Link tool Auto online setting Automatically detects an
NS-series PT connected serially
via an NT Link to a CS/CJ-series
PLC.
NT Link only No OK
DeviceNet
tool
Generic parameter
setting
Sends an explicit message. DeviceNet
only
OK OK
Edit Configuration
file
Edits each settings file. DeviceNet
only
OK OK
Edit configuration
file
Edits a variety of setting files. DeviceNet
only
OK OK
Install of plugin
module
Enables installing a plug-in
module.
DeviceNet
only
OK OK
Setup monitor
refresh timer
Set the monitor refresh timer for
the device monitor window.
DeviceNet
only
OK OK
Parameter auto
update when I/O
size changed
Enables automatically updating
the slave I/O size registered in the
scan list in the master when a
slave I/O size is changed. The
default setting is OFF (not
automatically updated). Normally,
leave this function set to OFF.
DeviceNet
only
OK OK
Controller
Link tool
Network Diagnosis Starts the Controller Link Network
Diagnosis Tool.
All networks No OK
Ping test Starts the Ethernet ping test tool. No OK Ethernet tool
Broadcast node
search
Uses IP broadcast to search for
nodes on Ethernet.
Ethernet only
OK OK
Echoback
test between
PLC nodes
Starts the echoback test tool for
checking the communications
status of the network.
No OK
CPS file Install CPS Installs a CPS file on the computer
and adds the component to the
CPS list.
All networks
OK OK
Install EDS Installs an EDS file on the
computer and adds the device to
the EDS list.
DeviceNet
only
OK OK
Create Creates a new EDS file on the
computer and adds the device to
the EDS list.
DeviceNet
only
OK OK
Delete Deletes an EDS file from the EDS
list.
DeviceNet
only
OK OK
Tools
EDS file
Save Saves an EDS file from the EDS
list in a file with a different name.
DeviceNet
only
OK OK
1-37
