2-1 Basic Procedures
Designing DeviceNet and CompoWay/F Networks Offline
Networks can be designed on the CX-Integrator even before they have been installed.
Parameters for individual DeviceNet masters and slaves can be set.
Parameters for individual CompoWay/F slaves can be set.
The specified parameters can be saved in project files.
All DeviceNet device and CompoWay/F component properties are included in the
project file (.cin).
Overall Procedure
Start the CX-Integrator.
Set master parameters.
Register slaves in the master.
Add devices to the virtual network.
Set slave parameters for slaves that require
setting.
Save everything in the project file (.cin).
Add CompoWay/F slaves to the virtual network.
●
DeviceNet Networks
Set CompoWay/F slave parameters.
●
CompoWay/F Networks
2-7
