CHAPTER 5 PARAMETERS
E5GN
5–6
Set point during SP ramp
The “SP ramp set value” parameter must not
be set to “OFF”.
This parameter monitors the set point during SP ramp.
Ramp" is a function for restricting the change width of the set point as a change rate.
The set value is displayed when SP ramp set value" parameter (advanced function
setting level) is set.
When the set point is out of the preset ramp, the set point is matched to the set point
set in the PV/SP" parameter.
Monitor Range Unit
SP: Set point lower limit to set point upper limit EU
FĂRelated parameters
PV/SP" (operation level)
SP ramp set value" (advanced function setting level)
Set point upper limit" Set point lower limit" (initial setting level)
Operation Level
Function
Monitor
See
