CHAPTER 5 PARAMETERS
E5GN
5–12
Set point 0
Set point 1
Set point 2
Set point 3
The “Multi-SP uses” parameter must be set to
“ON”.
These parameters set the set points when the multiĆSP function is used.
The values set in these parameters can be selected by operating the keys on the front
panel.
Ă• When the set point has been changed, the set value of these parameters currently
set by multiĆSP is linked and changed.
Ă• During temperature input, the decimal point position is dependent on the selected
sensor.
During analog input, the decimal point position is dependent on the setting of the
decimal point position" parameter.
Setting Range Unit Default
Set point lower limit to set point upper limit EU 0
FĂRelated parameters
PV/SP" (operation level)
Input type" (initial setting level)
MultiĆSP uses" (advanced function setting level)
Adjustment Level
Function
Setting
See
To Next Page
