Precautions for Correct Use
• Do not set EtherNet/IP and PLC Link at the same time. They cannot be used at the same
time.
Example
Set Serial (Ethernet) to PLC Link and Fieldbus to EtherNet/IP at the same time.
Set Serial (RS-232C/422) to PLC Link and Fieldbus to EtherNet/IP at the same time.
Set both Serial (Ethernet) and Serial (RS-232C/422) to PLC Link, and set Fieldbus to
EtherNet/IP at the same time.
• Do not set both Serial (Ethernet) and Serial (RS-232C/422) to PLC Link. They cannot be
used at the same time.
Additional Information
• Normal (Fxxx Series Method)
With the Normal communications method communications method, the OK response timing in
relation to MEASURE commands is different from that of the Normal communications method.
Normal (Fxxx series method) communications
method
Normal communications method
MEASURE
Measurement result
OK
MEASURE
OK
Measurement result
• OK Responses
With Normal communications method, an OK response is returned when the Controller re-
ceives a command.
With Normal (Fxxx series method), an OK response is returned when command execution is
completed.
Settings for Touch Panel Monitor
An exclusive touch screen monitor, Touch Panel Monitor is available for FH Sensor Controllers to con-
firm images or to display menus for condition settings.
Precautions for Correct Use
• The Touch Panel Monitor (FH-MT12) is used exclusively with the FH series Sensor Control-
lers. It cannot be used with FHV series Sensor.
• The Touch Panel Monitor (FH-MT12) is supported only by Ver. 5.32 or later versions of the
FH series Sensor Controller.
To wire the Touch Panel Monitor (FH-MT12) and an FH series Sensor Controller, a monitor cable for
video input and a touch panel cable for touch panel communication are required.
Normally, use a USB cable connection for the Touch Panel Monitor (FH-MT12).
4 Setting the Controller
4 - 7
FH/FHV Series Vision System User’s Manual (Z365-E1)
4-3 Setting Communication [Startup Settings]
4
To Next Page
