4 In the Adjustment Window (layout 0), click Data save in the Toolbox Pane to save the settings
data.
5
In the Main Window, select System restart from the Function menu.
The System restart dialog box is displayed.
6
Click OK.
Selection Guide for Operation mode
A guide to using the most suitable operation mode for your purpose.
Select Operation mode
You want to measure
on multiple lines.
Measures on multiple lines
: Trigger input for each line.
: Trigger input for each line.
You want to make
adjustments without
stopping
measurement.
Adjust without stopping
machines
: Can change the settings with
measuring.
: A part of the processing
items can be limited.
Executes the measurement as
many as possible by unit time.
: E xecutes the measurement alternately
using 2 cores. 2 core for fastest
measurement speed.
: For this measurement, need to use the
Multi-input function.
: A part of the processing items can be
limited.
You want to shorten the
single measurement time.
For fastest
measurement
processing time.
: No limit all f unctions.
4 Setting the Controller
4 - 12
FH/FHV Series Vision System User’s Manual (Z365-E1)
