Omron FHV7 series User Manual

Precautions for Correct Use
• Immediately after starting up the FH/FHV series Sensor Controller and immediately after
switching scenes, there will be no input image. No input image is processed as the same col-
or image as in the factory default state.
• If you open the Properties Dialog Box before inputting an image, click the Cancel button to
close the dialog box. Clicking the OK button in the dialog box will change the setting to the
same color camera setting as the factory default setting.
For details, refer toThe measurement NG (image mismatch) error will result when connecting
a monochrome camera. on page 11 - 11.
7 Increasing/Switching Measurement Scenes
7 - 5
FH/FHV Series Vision System User’s Manual (Z365-E1)
7-2 Switching the Scene or Scene Group
7
7-2-2 Switching Scene Groups
