Item
Setting value
[Factory default]
Description
Cell Align - Specifies the variable name for character string array that store
the character position per cell using up to 32 characters.
However, only variables in single dimensional array of character
string types that exist in the macro selected in Macro Type can be
specified.
The number of array elements must be the Col. Count or higher.
A separator character “;” needs to be added between cell data in
the same row.
A value stored in variables is below:
• 0: Left-aligned
• 1: Center
• 2: Right-aligned
If any of the following conditions are met, regardless of the set-
tings, all cells will be left-aligned.
• Variable is not specified.
• Specified variable does not exist.
Cells that meet any of the following conditions, regardless of the
settings, will be left-aligned.
• Value is not specified.
• Value is out of range
• Specified value is other than a numerical value.
Cell Edit Enable - Specifies the variable name for the character string array that
stores editing enabled or disabled per cell using up to 32 charac-
ters.
However, only variables in single dimensional array of character
string types that exist in the macro selected in Macro Type can be
specified.
The number of array elements must be the Col. Count or higher.
A separator character “;” needs to be added between cell data in
the same row.
A value stored in variables is below:
• 0: Editing enabled
• Other than 0: Editing disabled
If any of the following conditions are met, regardless of the set-
tings, all cells will be editing disabled.
• Variable is not specified.
• Specified variable does not exist.
Cells that meet any of the following conditions, regardless of the
settings, will be editing disabled.
• Value is not specified.
• Value is out of range
• Specified value is other than a numerical value.
8 Setting Windows
8 - 42
FH/FHV Series Vision System User’s Manual (Z365-E1)
