Item
Setting value
[Factory default]
Description
Max value -999999.9999 to
999999.9999
[-999999.9999]
Enter the maximum value that can be entered with the upper/
lower limit setting.
Min value -999999.9999 to
999999.9999
[-999999.9999]
Enter the minimum value that can be entered with the upper/
lower limit setting.
Precautions for Correct Use
• The limit box setting region sets an upper and lower limit for one data item. Accordingly, en-
sure upper and lower and limits for different data are not set.
• If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
Soft Keyboard Setting Region
Item
Setting value
[Factory default]
Description
Data Type
• [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
Sets the unit specification method for targets for which to carry
out soft keyboard setting.
The setting details vary depending on the specification meth-
od.
Target unit No. 0 to No. of units in
the display target
scene - 1 [0]
Use the unit number to specify the unit to be the target for the
soft keyboard setting.
The units that are registered for the scene that is the target of
the normal dialog box will appear in the combo box. Select the
processing unit to set.
Unit label
• [Unchecked]
• Checked
Sets when Unit data (No.) or Unit data (ident) is selected in
the Data Type.
If using the unit label to specify the unit to be the target for the
soft keyboard setting, select this, and set the unit label.
Target data No. 0 to 9999999 [0] Specify the data to be the target for the soft keyboard setting
using the data number.
Enter the data number for the unit that is specified by the
Target unit No..
Data reference but-
ton
- You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data
reference dialog box.
Data ident - Sets when Unit data (ident) is selected in the Data Type.
Use the unit identifier name to specify the unit to be the target
for the soft keyboard setting.
Ident 0
Ident 1
- These are available when System data is selected in the Data
Type.
Specify the system data to be the target for the soft keyboard
setting using the identifier information 0 and identifier informa-
tion 1. Refer to the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367) - system data
list.
8 Setting Windows
8 - 77
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-4 Editing contents are not reflected when you confirm the Sensor Controller after edit a layout by remote control
[Custom Dialog Tool]
8
8-4-2 Custom Dialog Tool
