Omron FHV7 series User Manual

Limit Box Setting Region
Item
Setting value
[Factory default]
Description
Lower limit
Upper limit
• [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
Sets the unit specification method for targets for which to carry
out upper/lower limits settings.
The setting details vary depending on the specification meth-
od.
Lower limit unit no.
Upper limit unit no.
0 to No. of units in
the display target
scene - 1 [0]
Sets when Unit data (No.) or Unit data (ident) is selected in
the Lower limit/Upper limit.
Use the unit number to specify the unit to be the target for the
upper/lower limit setting.
The units that are registered for the scene that is the target of
the normal dialog box will appear in the combo box. Select the
processing unit to set.
Lower limit unit la-
bel
Upper limit unit la-
bel
• [Unchecked]
• Checked
Sets when Unit data (No.) or Unit data (ident) is selected in
the Lower limit/Upper limit.
If using the unit label to specify the unit to be the target for the
upper/lower limit setting, select this, and set the unit label.
Lower limit data
no.
Upper limit data
no.
0 to 9999999 [0] Sets when Unit data (No.) is selected in the Lower limit/
Upper limit.
Specify the data to be the target for the upper/lower limit set-
tings using the data number.
Enter the data number for the unit that is specified by the
Target unit No..
Data reference but-
ton
- Sets when Unit data (No.) is selected in the Lower limit/
Upper limit.
You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data
reference dialog box.
Upper limit data
ident
Lower limit data
ident
- Sets when Unit data (ident) is selected in the Lower limit/
Upper limit.
Use the unit identifier name to specify the unit to be the target
for the upper/lower limit setting.
Ident 0
Ident 1
- Sets when System data is selected in the Lower limit/Upper
limit.
Specify the system data to be the target for the upper/lower
limit setting using the identifier information 0 and identifier in-
formation 1. Refer to the Vision System FH Series Macro
Customize Functions Programming Manual (Cat. No. Z367) -
system data list.
Upper limit scene
variable
Lower limit scene
variable
- Sets when Scene variable is selected in the Lower limit/
Upper limit.
Specify the scene variable to be the target for the upper/lower
limit settings using the scene variable name.
Upper limit system
variable
Lower limit system
variable
- Sets when System variable is selected in the Lower limit/
Upper limit.
Specify the system variable to be the target for the upper/
lower limit settings using the system variable name.
Decimal digits 0 to 4 [4] Enter the number of digits after the decimal place that can be
entered by the upper/lower limit setting.
8 Setting Windows
8 - 76
FH/FHV Series Vision System User’s Manual (Z365-E1)
