Omron FHV7 series User Manual

Item
Setting value
[Factory default]
Description
Unit label
• [Unchecked]
• Checked
This is available when Unit data (No.) or Unit data (ident) is
selected in the Data Type.
When using the unit label to specify the unit to be the target
for the numeric setting, select this and set the unit label.
Target data No. 0 to 9999999 [0] This is available when Unit data (No.) is selected in the Data
Type.
Enter the data number for the unit that is specified by the
Target unit No..
Data reference but-
ton
- This is available when Unit data (No.) is selected in the Data
Type.
You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data
reference dialog box.
Data ident - Sets when Unit data (ident) is selected in the Data Type.
Use the unit data (identifier name) to specify the unit to be the
target for the numeric setting.
Ident 0
Ident 1
- These are available when System data is selected in the Data
Type.
Specifies the system data to be the target for the numeric set-
ting using the identifier information 0 and identifier information
1. Refer to the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367) - system data
list.
Scene variable - This is available when Scene variable is selected in the Data
Type.
Specifies the scene variable to be the target for the numeric
setting using the scene variable name.
System variable - This is available when System variable is selected in the Data
Type.
Specifies the system variable to be the target for the numeric
setting using the system variable name.
Decimal digits 0 to 4 [4] Enter the number of digits after the decimal place that can be
entered by the numeric setting.
Max value -999999.9999 to
999999.9999
[-999999.9999]
Enter the maximum value that can be entered with the numer-
ic setting.
Min value -999999.9999 to
999999.9999
[-999999.9999]
Enter the minimum value that can be entered with the numeric
setting.
Precautions for Correct Use
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
8 Setting Windows
8 - 75
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-4 Editing contents are not reflected when you confirm the Sensor Controller after edit a layout by remote control
[Custom Dialog Tool]
8
8-4-2 Custom Dialog Tool
