Item
Setting value
[Factory default]
Description
Ident 0
Ident 1
- These are available when System data is selected in the Data
Type.
Specify the system data to be the target for the radio button
setting using the identifier information 0 and identifier informa-
tion 1. Refer to the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367) - system data
list.
Scene variable - This is available when Scene variable is selected in the Data
Type.
Specify the scene variable to be the target for the radio button
setting using the scene variable name.
System variable - This is available when System variable is selected in the Data
Type.
Specify the system variable to be the target for the check box
setting using the system variable name.
Precautions for Correct Use
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
Combo Box Setting Region
Item
Setting value
[Factory default]
Description
Data Type
• [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
Sets the unit specification method for targets for which to carry
out combo box settings.
The setting details vary depending on the specification meth-
od.
Target unit No. 0 to No. of units in
the display target
scene - 1 [0]
Use the unit number to specify the unit to be the target for the
combo box setting.
The units that are registered for the scene that is the target of
the normal dialog box will appear in the combo box. Select the
processing unit to set.
Unit label
• [Unchecked]
• Checked
This is available when Unit data (No.) or Unit data (ident) is
selected in the Data Type.
If using the unit label to specify the unit to be the target for the
combo box setting, select this and set the unit label.
Target data No. 0 to 9999999 [0] Specify the data to be the target for the combo box setting us-
ing the data number.
Enter the data number for the unit that is specified by the
Target unit No..
Data reference but-
ton
- You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data
reference dialog box.
Data ident - Sets when Unit data (ident) is selected in the Data Type.
Use the unit data (identifier name) to specify the unit to be the
target for the combo box setting.
8 Setting Windows
8 - 80
FH/FHV Series Vision System User’s Manual (Z365-E1)
