Omron FHV7 series User Manual

Item
Setting value
[Factory default]
Description
Ident 0
Ident 1
- These are available when System data is selected in the Data
Type.
Specify the system data to be the target for the combo box
setting using the identifier information 0 and identifier informa-
tion 1. Refer to the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367) - system data
list.
Scene variable - This is available when Scene variable is selected in the Data
Type.
Specify the scene variable to be the target for the radio button
setting using the scene variable name.
System variable - This is available when System variable is selected in the Data
Type.
Specify the system variable to be the target for the radio but-
ton setting using the system variable name.
Item setting button - Sets the item name and the data that corresponds to the item
name to display in the combo box. Make sure the number of
items and the number of data match.
Items:
Enter the name of the items to display in the combo box.
Data No.:
Enter the target data numbers that correspond to each item in
the combo box.
Precautions for Correct Use
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
Image Button Setting Region
Item
Setting value
[Factory default]
Description
Event
• [Apply and
close]
• Close
• Other dialog
• Apply and
change dialog
• Change dialog
• Apply
• Get current val-
ue
• Set Value
Sets the event to click the button.
• Apply and close: Apply the settings and close the dialog.
• Close: Close the dialog.
• Other dialog: Open a child window for the new dialog.
• Apply and change dialog: Apply the settings and open the
specified dialog.
• Change dialog: Open the specified dialog without applying
the settings.
• Apply: Apply the settings.
• Get current value: Restore the data before application.
• Set value: Set the specified value to the specified data.
Target dialog ID Dialog 1 to 6 This is available when Other dialog, Apply and change dialog,
or Change dialog is selected in the Event.
Variable - This is available when Other dialog, Apply and change dialog,
or Change dialog is selected in the Event.
8 Setting Windows
8 - 81
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-4 Editing contents are not reflected when you confirm the Sensor Controller after edit a layout by remote control
[Custom Dialog Tool]
8
8-4-2 Custom Dialog Tool
