Omron FHV7 series User Manual

Item
Setting value
[Factory default]
Description
Data Type
• [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
This is available when Set Value is selected in the Event.
Sets the unit specification method for targets for which to carry
out image button settings.
The setting details vary depending on the specification meth-
od.
Target unit No. 0 to No. of units in
the display target
scene - 1 [0]
This is available when Set Value is selected in the Event.
This is available when Unit data (No.) or Unit data (ident) is
selected in the Data Type.
The units that are registered for the scene that is the target of
the normal dialog box will appear in the combo box. Select the
processing unit to set.
Unit label
• [Unchecked]
• Checked
This is available when Set Value is selected in the Event.
This is available when Unit data (No.) or Unit data (ident) is
selected in the Data Type.
If using the unit label to specify the unit to be the target for the
image button setting, select this, and set the unit label.
Target data No. 0 to 9999999 [0] This is available when Set Value is selected in the Event.
This is available when Unit data (No.) is selected in the Data
Type.
Specifies the data to be the target for the image button setting.
Enter the data number for the unit that is specified by the
Target unit No..
Data reference but-
ton
- This is available when Set Value is selected in the Event.
This is available when Unit data (No.) is selected in the Data
Type.
You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data
reference dialog box.
Data ident - This is available when Set Value is selected in the Event.
Sets when Unit data (ident) is selected in the Data Type.
Use the unit data (identifier name) to specify the unit to be the
target for the image button setting.
Ident 0
Ident 1
- This is available when Set Value is selected in the Event.
These are available when System data is selected in the Data
Type.
Specifies the system data to be the target for the image button
setting using the identifier information 0 and identifier informa-
tion 1. Refer to the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367) - system data
list.
Scene variable - This is available when Set Value is selected in the Event.
This is available when Scene variable is selected in the Data
Type.
Specifies the scene variable to be the target for the image but-
ton setting using the scene variable name.
System variable This is available when Set Value is selected in the Event.
This is available when System variable is selected in the Data
Type.
Specifies the system variable to be the target for the image
button setting using the system variable name.
Value - Sets a value.
8 Setting Windows
8 - 82
FH/FHV Series Vision System User’s Manual (Z365-E1)
