Outputting Data and Controlling Operation through EtherNet/IP
304
FQ2 User’s Manual
Accessing Communications Areas Using Variables with NJ-series Controllers
With an NJ-series Controller, only variables can be used to access from the user program the I/O memory
addresses that are assigned to the communications areas.
Use the following settings.
● Using Network Variables for Access
Create user-defined variables that match the structures of the communications areas of the Sensor.
Use the Sysmac Studio to define the variables.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for Sysmac Studio operating
procedures.
1 Defining the Data Types of the Variables
Define data types for variables that match the structures of the communications areas.
(1) Defining a Data Type for Signal Access
First, define a BOOL array data type to access the control signals and status signals.
Here, a data type called “U_EIPFlag” is defined.
Name of data type: U_EIPFlag
Type of derivative data type: Union
(2) Defining Data Types for Communications Area Access
Data types are defined to access the communications areas, with one data type for the command area
and another data type for the response and output areas.
Here, data types called “S_EIPOutput” and “S_EIPInput” are defined.
• Data Type to Access the Command Area
Name of data type: S_EIPOutput
Type of derivative data type: Structure
U_EIPFlag
F
UNION
Data typeName of data type
ARRAY[0..31]OF BOOL
Specifies an array of
BOOL data from 0 to 31.
W
DWORD
32-bit bit string data
Name of data type Data type
S_EIPOutput STRUCT
ControlFlag U_EIPFlag
The data type that was defined above (1)
CommandCode DWORD 32-bit bit string data
CommandParam2 UDINT32-bit integer data
CommandParam3 DINT32-bit integer data
CommandParam1 UDINT32-bit integer data
