Outputting Data and Controlling Operation through EtherNet/IP
308
FQ2 User’s Manual
Example: Setting Example for Variables to Access the Command Area
Commands (EtherNet/IP)
This section describes the EtherNet/IP commands.
● Measurement Control Commands
● Utility Commands
● Scene Control Commands
Command code in
command area (hex)
Command name Function Reference
00101020 Start Continuous Measure-
ments
Executes continuous measurements. p. 309
00101030 End Continuous Measure-
ments
Ends continuous measurements.
p. 310
Command code in
command area (hex)
Command name Function Reference
00102010 Clear Measurement Values Clears all measurement result values. p. 310
00102020 Clear Data Output Buffer Clears all data in the data output buffer.
p. 311
00103010 Save Data in Sensor Saves scene data and system data. p. 311
00104010 Re-register Model Registers the model again for registered
Search Position Compensation, Shape
Search II Position Compensation, Search,
Shape Search II, or Sensitive Search inspec-
tion items.
p. 312
00104020 Teach Executes teaching for all inspection items.
p. 312
0010F010 Reset Resets the Vision Sensor. p. 313
00205000 Get Latest Error Information Acquires the latest error information.
p. 313
Command code in
command area (hex)
Command name Function Reference
00201000 Get Scene Number Acquires the current scene number. p. 314
00301000 Select Scene Changes to the specified scene number.
p. 314
15 10
EXE
DSA
Settings
Variable name
AT
specification
Data type
Command Area (PLC Output Tag D0)
Variables Used to Access the Command Area
in the PLC from the User Program
I/O memory
address
D0
D1
TRIGERCLR
a (Assigned to the EXE signal.)
D0.0 BOOL
b (Assigned to the TRIG signal.)
D0.1
BOOL
c (Assigned to the ERCLR signal.)
D0.15
BOOL
d (Assigned to the DSA signal.) D1.0 BOOL
