Outputting Data and Controlling Operation through EtherNet/IP
FQ2 User’s Manual
313
Connecting through Ethernet
9
● Reset Vision Sensor (Command Code: 0010 F010)
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
If you leave the EXE signal ON when you use it to execute the Reset command, the Vision Sensor will restart
repeatedly.
After you execute the Reset command, turn OFF the EXE signal before the Vision Sensor restarts.
● Get Latest Error Information (Command Code: 0020 5000)
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
First word of
command
area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 1111 0000 0001 0000 Command code
+3 0000 0000 0001 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
There is no response for a reset operation.
First word of
command
area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0101 0000 0000 0000 Command code
+3 0000 0000 0010 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0101 0000 0000 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0010 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Response data
Latest error code
Errors Stored in the Error
History p. 398
+7 0000 0000 0000 0000
Important
