Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
FQ2 User’s Manual
381
Connecting through Ethernet
9
Saving Data in the Sensor: 280F 00103010
This command saves the current setting data (system data, scene groups, and calibration data) in the Sensor.
● Format
● Response Format
● End Codes
Re-registering Models: 280F 00104010
This command re-registers the models for registered Search and Color Data inspection items.
● Format
● Response Format
● End Codes
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00103010
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00103010
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00104010
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00104010
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
