A-1 Connecting the 1S-series Servo Drive
A
A-1-2 Servo Drive Settings
 Trigger Signal Assignments for External Latches
The input signals in the following table are assigned to external latch trigger signals by default for
the OMRON 1S-series Servo Drive.
*1 The signal name for the Servo Drive is the external latch input 1.
*2 The signal name for the Servo Drive is the external latch input 2.
The MC Function Module does not perform backlash compensation.
If you require backlash compensation, use the compensation function on the Servo Drive.
The objects that must be set on the Servo Drive are listed in the following table.
*1 The default setting is 0: Backlash compensation disabled.
For details on the backlash function, refer to the AC Servomotors/Servo Drives 1S-series with Built-in
EtherCAT Communications User’s Manual (Cat. No. I586).
Settings for the TriggerInput (Trigger Input Condition)
input variable of the MC_TouchProbe instruction
External latch trigger signal
Mode InputDrive LatchID
0: mcDrive 0: mcEncoderMark --- Encoder Z phase
1: mcEXT 1: mcLatch1 Servo Drive general-purpose input 7
(IN7: pin 15 on connector CN1, NO)
*1
2: mcLatch2 Servo Drive general-purpose input 8
(IN8: pin 35 on connector CN1, NO)
*2
1: mcController --- --- Variable specified by TriggerVariable
Backlash Compensation
Index
Subin-
dex
Name Description
3001 hex --- Machine ---
02 hex Backlash Compensation
Selection
Selects whether to enable or disable backlash compen-
sation in the position control, and the operation direc-
tion for the compensation.
*1
0: Backlash compensation disabled
1: Compensate at the first positive operation after servo
ON
2: Compensate at the first negative operation after
servo ON
03 hex Backlash Compensation
Amount
Sets the backlash compensation amount in the position
control.
04 hex Backlash Compensation
Time Constant
Sets the backlash compensation time constant in the
position control.
