Omron NX701-1 User Manual

3 Configuring Axes and Axes Groups
3-4
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
Operation Set-
tings
Maximum Velocity
Start Velocity
*4
Maximum Jog Velocity
Maximum Acceleration
Maximum Deceleration
Acceleration/Deceleration Over
Operation Selection at Reversing
Velocity Warning Value
Acceleration Warning Value
Deceleration Warning Value
Positive Torque Warning Value
*5
Negative Torque Warning Value
*5
Actual Velocity Filter Time Constant
In-position Range
In-position Check Time
Zero Position Range
Other
Operation Set-
tings
Immediate Stop Input Stop Method
Limit Input Stop Method
Drive Error Reset Monitoring Time
Maximum Positive Torque Limit
Maximum Negative Torque Limit
Immediate Stop Input Logic Inversion
*4
Positive Limit Input Logic Inversion
*4
Negative Limit Input Logic Inversion
*4
Home Proximity Input Logic Inversion
*4
Limit Settings Software Limits
Positive Software Limit
Negative Software Limit
Following Error Over Value
Following Error Warning Value
Position Count
Settings
Count Mode
Modulo Maximum Position Setting Value
Modulo Minimum Position Setting Value
Encoder Type
Servo Drive
Settings
Modulo Maximum Position Setting Value
Modulo Minimum Position Setting Value
PDS State Control Method
Classification Parameter name
