User Parameter Tables
5-27
îš„Multi-function Analog Outputs: H4
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
H4-01
Terminal FM
monitor selection
Sets the number of the monitor
item to be output (U1-) at ter-
minal FM.
1 to 53 2 No A 41DH 6-67
H4-02
Terminal FM
gain
Sets the analog output FM gain.
Sets the percentage of the monitor
value that is equal to 10 V output at
terminal FM.
Note that the maximum output
voltage is 10 V.
0 to
1000.0
%
100% Yes A 41EH 6-67
H4-03 Terminal FM bias
Sets the analog output FM bias.
Sets the percentage of the monitor
item that is equal to 0 V output at
terminal FM.
The maximum output from the ter-
minal is 10 V.
-110.0
to
+110.0
%
0.0% Yes A 41FH 6-67
H4-04
Terminal AM
monitor selection
Sets the number of the monitor
item to be output (U1-) at ter-
minal FM.
1 to 53 8 No A 420H 6-67
H4-05
Terminal AM
gain
Sets the analog output AM gain.
Sets the percentage of the monitor
value that is equal to 10V output at
terminal AM.
Note that the maximum output
voltage is 10V.
0 to
1000.0
%
50.0% Yes A 421H 6-67
H4-06
Terminal AM
bias
Sets the analog output AM bias.
Sets the percentage of the monitor
item that is equal to 0 V output at
terminal AM.
The maximum output from the ter-
minal is 10 V.
-110.0
to
+110.0
%
0.0% Yes A 422H 6-67
H4-07
Terminal FM sig-
nal level selection
Sets the signal output level for
multi-function output 1 (terminal
FM)
0: 0 to +10 V output
2: 4 – 20 mA
*1
*1. An analog output signal of 4 - 20 mA requires an optional terminal board (ETC618121) for current output
0 or 2 0 No A 423H 6-67
H4-08
Terminal AM
signal level selec-
tion
Sets the signal output level for
multi-function output 2 (terminal
AM)
0: 0 to +10 V output
2: 4 – 20 mA
*1
0 or 2 0 No A 424H 6-67
