If it is set to Static IP, then a fixed IP address and subnet mask must be set.
•
If it is set to Default Static IP, the fixed IP revert to the factory default and cannot be
changed.
After all parameters are set, click on the Save button to store the new values permanently.
Wait 1 minute and reconnect to the device using the new settings.
Compute Box / Eye Box settings:
In case, more than one Compute Box is used within the same network, for
identification
purpose any user specific name can be entered to the Display name.
EtherNet/IP scanner settings:
NOTE:
This is a special option of the EtherNet/IP connection for some robots.
In case when the robot is the Adapter and the Compute Box needs to be the Scanner the
following addition information is required for the communication:
•
IP address to connect to - the robot IP address
•
Origin-to-target instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
•
Target-to-origin instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
•
Configuration instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
•
Requested packet interval (ms) - RPI value in ms (minimum 4)
Check the checkbox and the Compute Box will try to automatically connect to the robot (via
the given IP address).
7.1.5. Web Client: Path Menu
NOTE:
The Path feature may not be available to your robot type.
This page can be used to import, export, and delete the previously recorded paths. In this way
a Path can be copied to a dierent Compute Box.
