Screw
standard
Din 912 /
ISO 4762 /
ISO 14579 /
ISO 14580 /
ASME
B18.3 Hex
Cylinder
ISO 14581 /
ASME
B18.6 HEX
Counter
sunk /
ASME
B18.6.3
Torx
Counter
sunk
DIN 7985A /
ASME
B18.6.3
Cross
recessed
Button
head /
ASME
B18.6.3 Torx
Button head
Screw-bit
System
appearance
5. Attaching and Detaching the Screw-bit System to/from the Screwdriver
The last step is to attach the system to the Screwdriver by placing the hex shape of the bit
holder inside of the end of the screwdriver's shank as shown in the picture below. The system
will be attached to the screwdriver by a magnetic force.
