Operating Conditions Minimum Typical Maximum Unit
Relative humidity (non-condensing) 0 - 95 [%]
Calculated MTBF (operating life) 30.000 - - [hours]
2 Channels
The VGC10 has 4 holes to use
fittings with vacuum cups or blinding screws as needed. It also
has lines which show the holes that are communicated together. This is useful when using
channels A and B independently for vacuum.
Adaptor Plate
The VGC10 comes with an Adaptor Plate which provides extra flexibility to locate the vacuum
cups in dierent configurations.
The Adaptor Plate has 7 holes to use fittings with vacuum cups or blinding screws as needed.
It also has lines which show the holes that are communicated together. This is useful when
using channel A and B independently for vacuum.
HARDWARE SPECIFICATION
