Maintenance
Version 1.0.4 - 2020-08-04 59Translation of original instruction
MT60 EN
MT60_GB_5.fm
The first time
after 3 month,
then every
6 months
Feed gear
Oil change
For oil change use an appropriate collecting tray of suffi-
cient capacity.
Travel the table in the rapid mode back and forth, the oil
heats up and easily penetrates from the drain opening.
Unscrew the screw from the drain hole.
Unscrew the screw from the filler hole.
Img.6-3: Filler hole feed gear
Close the drain hole if no more oil drains.
Fill up to the middle of the reference mark of the oil sight
glass into the filler hole using a suitable container.
The first time
after 20 hours
of operation,
then every
month
V-belt
Horizontal milling
Check
Readjusting
Check if the V-belts are porous or worn.
Press the finger on the V-belt. The V-belt should push
through by about 5 mm at a force of about 30 Newton (3
kg).
Interval Where? What? How?
