Checking DIMM Compatibility
■
Both memory risers must be installed, and both fully occupied.
Note - The DIMM sparing feature is available only when the optional memory risers are
installed and fully occupied.
Related Information
■
“Checking DIMM Compatibility” on page 84
■
“Memory Riser and DIMM FRU Names” on page 85
■
“Locate a Faulty DIMM (Fault Remind Button)” on page 90
■
“Remove a Memory Riser” on page 91
■
“Remove a DIMM” on page 95
■
“Install a DIMM” on page 96
Checking DIMM Compatibility
Each DIMM is affixed with an identifying label. The first four characters on the label describe
the DIMM memory capacity; the second four characters describe the rank classification.
Use these labels to identify the DIMMs installed in the server, to verify that any replacement
DIMMs are compatible, or to confirm that upgrade DIMMs may be installed in a supported
configuration.
84 SPARC T8-1 Server Service Manual • January 2022
