Install a Drive or Drive Filler
■
“Verify a Drive” on page 66
Install a Drive or Drive Filler
Installing a drive into a server is a two-step process. You must first install the drive into the
drive slot and then configure that drive to the server.
Note - If you removed an existing drive from a slot in the server, you must install the
replacement drive in the same slot as the drive that was removed. Drives are physically
addressed according to the slot in which they are installed.
1.
Unpack the drive and place it on an antistatic mat.
2.
Fully open the release lever on the drive.
3.
Install the drive or drive filler by completing the following tasks.
a.
Slide the drive or drive filler into the drive slot until it is fully seated.
b.
Close the latch to lock the drive or drive filler in place.
Servicing Drives 65
