Add Memory to the Server
Physical Location (Seen From Rear) Memory Riser or DIMM FRU Name
5
6
7
8
/SYS/MB/CM/CMP/BOB30/CH1
/SYS/MB/CM/CMP/BOB20/CH0
/SYS/MB/CM/CMP/BOB20/CH1
Right motherboard
9
10
11
12
/SYS/MB/CM/CMP/BOB10/CH1
/SYS/MB/CM/CMP/BOB10/CH0
/SYS/MB/CM/CMP/BOB00/CH1
/SYS/MB/CM/CMP/BOB00/CH0
Right memory riser
13
14
15
16
/SYS/MB/CM/CMP/MR0 (riser)
/SYS/MB/CM/CMP/MR0/BOB01/CH1
/SYS/MB/CM/CMP/MR0/BOB01/CH0
/SYS/MB/CM/CMP/MR0/BOB21/CH1
/SYS/MB/CM/CMP/MR0/BOB21/CH0
Related Information
■
“Memory Riser and DIMM Configuration” on page 83
■
“Checking DIMM Compatibility” on page 84
■
“Locate a Faulty DIMM (Fault Remind Button)” on page 90
■
“Locate a Faulty DIMM (Oracle ILOM)” on page 89
■
“Enable and Verify a DIMM” on page 103
Add Memory to the Server
Caution - These procedures require that you handle components that are sensitive to ESD.
Follow antistatic practices to avoid damage or component failure.
Customers can perform this procedure, but the server must first be completely powered down
and all power cords unplugged. See “Component Service Categories” on page 43 for more
information about cold-service procedures.
Servicing Memory Risers and DIMMs 87
