Planning and Preparation 2-1
2 Planning and Preparation
Rack Preparation
■ It is suggested that you position the power distribution unit on the right side of
the rack as viewed from the rear of the rack (see Figure 2–1). The power supply
outlets are on the right side of the SL150 library.
Figure 2–1 Rear View of Sun Rack II (PDU on RIght Side)
Illustration Legend:
1 - Power Distribution Unit (PDU)
Note: The installation instructions in this guide are based upon
the Sun Rack II which is the standard Oracle 19-inch rack.
