Oracle X7-2 Installation Guide

Receiving and Unpacking Requirements
Dimension Server Specification Measurement
Weight Fully populated server 40 lbs (18.1 kg)
Oracle Server X7-2L:
Dimension Server Specification Measurements
Width Server chassis 48.2 cm ( 18.9 inches)
Depth Maximum overall 75.9 cm (29.9 inches)
Height 2-rack unit (2U) nominal 8.69 cm (3.42 inches)
Weight Fully populated server 64 lbs (29.03 kg)
Receiving and Unpacking Requirements
When the server is unloaded at your site:
■
Leave the server in its shipping carton until it arrives at its installation location.
■
Use a separate area to remove the packaging material to reduce particle contamination
before the server is taken to the data center.
■
Ensure that there is enough clearance and clear pathways to move the server from the
unpacking area to the installation location.
■
Ensure the entire access route to the installation site is free of raised-pattern flooring that
causes vibration.
Rack Space Requirements
The Oracle Server X7-2 is a 1 rack unit (1U) server. Oracle Server X7-2L is a 2U server. For
physical dimensions, see “Server Physical Specifications” on page 13.
You can install the server into a four-post rack cabinet that conforms to ANSI/EIA 310-D-1992
or IEC 60297 standards, such as Oracle Rack Cabinet 1242 or Sun Rack II 1242. See “Rack
Compatibility” on page 41.
The minimum ceiling height for the cabinet is 230 cm (90 inches), measured from the true
floor or raised floor, whichever is higher. An additional 91.4 cm (36 inches) of ceiling height is
required for top clearance. The space above the cabinet and its surroundings must not restrict
14 Oracle Servers X7-2 and X7-2L Installation Guide • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
