Oracle X7-2 Installation Guide

Rack Compatibility
Item Requirement
■ Two-post racks are not compatible.
Rack horizontal opening and unit vertical pitch Conforms to ANSI/EIA 310-D-1992 or IEC 60297
standards.
Distance between front and back mounting planes Minimum 61 cm and maximum 91.5 cm (24 inches to 36
inches).
Clearance depth in front of front mounting plane Distance to front cabinet door is at least 2.54 cm (1 inch).
Clearance depth behind front mounting plane Distance to back cabinet door is at least 90 cm (35.43
inches) with the cable management arm, or 80 cm (31.5
inches) without the cable management arm.
Clearance width between front and back mounting planes Distance between structural supports and cable troughs is
at least 45.6 cm (18 inches).
Minimum clearance for service access ■ Clearance, front of server: 123.2 cm (48.5 inches)
■ Clearance, back of server: 91.4 cm (36 inches)
The following table contains Sun Rack II Model 1242 and Sun Rack II Model 1042 rack
specifications.
Requirement Specification
Usable rack units 42
Height 199.8 cm (78.66 inches)
Width (with side
panels)
60 cm (23.62 inches)
Depth Model 1242
†
120 cm (47.24 inches)
Weight Model 1042 123.4 kg (272 lbs)
Depth Model 1042
‡
105.8 cm (41.66 inches)
Weight Model 1242 150.6 kg (332 lbs)
Maximum dynamic
load
1005 kg (2215 lbs)
†
Depth is measured from front door handle to back door handle.
‡
Depth is measured from front door handle to back door handle.
The following table contains the Oracle Rack Cabinet 1242 rack specifications:
Requirement Specification
Usable rack units 42
Height 199. cm (78.74 inches)
Width (with side
panels)
60 cm (23.62 inches)
42 Oracle Servers X7-2 and X7-2L Installation Guide • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
