Oracle X7-2 Installation Guide

Install the Server Into the Slide-Rail Assemblies
■
“Mark the Rackmount Location” on page 46
■
“Install the Server Into the Slide-Rail Assemblies” on page 52
Install the Server Into the Slide-Rail Assemblies
Use this procedure to install the server chassis with mounting brackets into the slide-rail
assemblies that are mounted to the rack.
Caution - Personal Injury or Equipment Damage: This procedure requires a minimum of
two people because of the weight of the server. Attempting this procedure alone could result in
equipment damage or personal injury.
Caution - Personal Injury or Equipment Damage: Always load equipment into a rack from
the bottom up so that the rack does not become top-heavy and tip over. Extend the rack anti-tilt
bar to prevent the rack from tipping during equipment installation.
1.
Push the slide-rails as far as possible into the slide-rail assemblies in the rack.
2.
Position the server so that the back ends of the mounting brackets are aligned
with the slide-rail assemblies that are mounted in the rack.
52 Oracle Servers X7-2 and X7-2L Installation Guide • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
