Oracle X7-2 Installation Guide

Rackmount Kit Contents
Requirement Specification
Maximum dynamic
load
1005 kg (2215 lbs)
Related Information
■
“Preparing for Server Installation” on page 13
Rackmount Kit Contents
The following figure shows the Rackmount Kit contents. For instructions on how to install your
server in a four-post rack using the slide-rail and cable management arm options, refer to the
Rackmounting Template.
Call Out Description
1 Slide-rails
2 Mounting brackets
3 Four M4 x 5 fine-pitch mounting bracket securing screws (optional)
4 Rackmounting Template
Related Information
■
“Rack Compatibility” on page 41
Installing the Server Into a Rack 43

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
