Oracle X7-2 Installation Guide

X7-2 Front Panel Features
Feature System Components
■ Support for Ethernet access to the SP through a dedicated management port
(NET MGT) and optionally through one of the host Ethernet ports (sideband
management)
■ Support for remote KVMS (keyboard, video, mouse, and storage) over IP
Management software ■ Oracle Integrated Lights Out Manager (ILOM) on the service processor
■ Oracle Hardware Management Pack, included as part of the Oracle Solaris
OS starting with Oracle Solaris 11.2, or available as a standalone product for
other supported operating systems. Refer to the support matrix for specific
information: http://www.oracle.com/goto/ohmp
Power supplies Two hot-swappable and highly-redundant 1200W power supplies.
Cooling fans (Oracle Server
X7-2)
Four 40-mm, hot-swappable fan modules for chassis cooling. Each fan module
contains two counter-rotating fan pairs.
Each power supply has its own cooling fans.
Cooling fans (Oracle Server
X7-2L)
Four 80-mm, hot-swappable fan modules for chassis cooling. Each fan module
contains one pair of counter-rotating fans.
Each power supply has its own cooling fans.
Operating systems and
virtualization software
■ Oracle Solaris
■ Oracle Linux
■ Oracle VM
■ Microsoft Windows Server
■ VMware ESXi
Related Information
■
“X7-2 Front Panel Features” on page 27
■
“X7-2 Back Panel Features” on page 29
X7-2 Front Panel Features
The following figure shows the status indicators (LEDs), connectors, and drives located on the
front panel of Oracle Server X7-2 with eight 2.5-inch storage drives.
For information about how to interpret the status indicators (LEDs), refer to the Oracle Server
X7-2 Service Manual.
Server Features and Components 27

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
