Oracle X7-2 Installation Guide

Server Components
Feature System Components
Note - NVMe SSDs are supported only on servers running Oracle Linux or Oracle
Solaris operating systems.
Storage Drives
(Oracle Server X7-2L)
The storage drive configuration can comprise both hard disk drives (HDDs) or solid
state drives (SSDs). The configuration includes:
■ Up to twelve 3.5-inch hot-pluggable SAS3/SATA3 HDDs/SSDs, or optional
support for up to twelve 2.5-inch NVM-Express (NVMe) SSDs
■ Two internal hot-pluggable SATA/PCIe M.2 flash modules
Note - The NVM-Express PCIe switch card is required for storage drive
configurations that contain NVMe SSDs.
Note - NVMe SSDs are supported only on servers running Oracle Linux or Oracle
Solaris operating systems.
PCI Express (PCIe) slots
(Oracle Server X7-2)
Four PCIe Gen3 slots that accommodate low-profile PCIe cards.
■ Slots 1 and 2: x16 electrical interface
■ Slot 3: x8 electrical interface
■ One additional internal x8 PCIe slot for use with an optional internal host bus
adapter (HBA) card. This internal HBA card is used to control and manage the
storage drives.
Note - PCIe slot 1 is nonfunctional in single-processor systems.
PCI Express (PCIe) slots
(Oracle Server X7-2L)
Eleven PCIe Gen3 slots that accommodate low-profile PCIe cards.
■ Slots 1 and 7: x16 electrical interface
■ Slots 1 through 6, and slots 8 through 11: x8 electrical interface
Note - PCIe slots 1 through 5 are nonfunctional in single-processor systems.
I/O ports (Oracle Server X7-
2)
■ One RJ-45 serial management (SER MGT) port
■ One 10/100/1000BASE-T RJ-45 Oracle Integrated Lights Out Manager (ILOM)
service processor (SP) network management (NET MGT) port
■ One 10/100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port, labeled NET 0
■ Two 10/25GbE SFP+ Ethernet ports, labeled NET 1 and NET 2
■ Two 10GBASE-T RJ-45 Gigabit Ethernet (GbE) ports, labeled NET 1 and NET
2
Note - The 10/25GbE SFP+ Ethernet ports (NET 1 and NET 2) are the default
network ports for the server. When using an SFP+ port, network connectivity is
disabled on the 10GBASE-T RJ-45 GbE (NET 1 and NET 2) Ethernet ports.
I/O ports (Oracle Server X7-
2L)
■ One RJ-45 serial management (SER MGT) port
■ One 10/100/1000BASE-T RJ-45 Oracle Integrated Lights Out Manager (ILOM)
service processor (SP) network management (NET MGT) port
■ One 10/100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port, labeled NET 0
USB 3.0 ports One back panel, and one internal.
Service processor (SP) The server has an integrated service processor (SP), features include:
■ Oracle Integrated Lights Out Manager (ILOM) version 4.0
■ Local Oracle ILOM command-line access using a serial connection
26 Oracle Servers X7-2 and X7-2L Installation Guide • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
