Oracle X7-2 Installation Guide

X7-2L Back Panel Features
Call Out Description
3 Power supply unit 1 (PSU1)
4 Power Supply (PS) 1 status indicators: Service Required LED: amber AC OK LED: green
5 PCIe slot 1 (Nonfunctional in single-processor systems)
6 PCIe slot 2 (Nonfunctional in single-processor systems)
7 PCIe slot 3 (Nonfunctional in single-processor systems)
8 PCIe slot 4 (Nonfunctional in single-processor systems)
9 PCIe slot 5 (Nonfunctional in single-processor systems)
10 PCIe slot 6
11 Serial management (SER MGT) RJ-45 serial port
12 Oracle Integrated Lights Out Manager (ILOM) service processor (SP) network management
(NET MGT) RJ-45 10/100/1000BASE-T port
13 Network (NET) 10/100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port: NET 0
14 USB 3.0 connector
15 System status LEDs: Locate/Button: white; Fault - Service Required: amber; System OK:
green
16 PCIe slot 7
17 PCIe slot 8
18 PCIe slot 9
19 PCIe slot 10
20 PCIe slot 11
Related Information
■
“X7-2L Front Panel Features” on page 30
■
“Server Components” on page 25
Server Features and Components 33

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
